ULSTEIN SX197 Shanghai Electric

ZHI CHENG 60

Service Operation Vessel (SOV) for the offshore wind industry in China. Based on the ULSTEIN SX197 design, featuring the X-BOW and X-STERN for soft motions and increased comfort.

Owned By
Shanghai Electric Windpower Group
Built By
Partner yard
Year
2024
Operated By
Shanghai Electric

Primary Specifications

Length
72.6 m
Beam
17.5 m
Dead weight
1,925.9 tonnes
Draught (max)
5.5 m
Speed (max)
13.0 kn
Accommodation
60 POB

Additional Data

Deck area - cargo deck
200 sqm
Deck area - warehouse
200 sqm
Fuel oil, cargo & domestic
567.82 cbm
Fresh water
522.07 cbm
Ballast water
1,566.43 cbm
Sewage
39.54 cbm
Note: Specifications may have changed since the original completion date.
Classifications: SPS, In-WaterSurvey, CSMAUT-0, DP2, G-ECO(BWM(T), NOI1, VIB1), G-EP(GPR, OIL1, RSC1, AFS), Hybrid, CSAOffshoreEngineeringSupportShip'

Ship history

In 2022, Shanghai Electric Windpower Group ordered two Service Operation Vessels (SOVs) based on two different Ulstein designs to be constructed at the ZPMC shipyard in China. These are the first purpose-made SOVs designed for the Chinese Offshore Wind industry.

Milestones in the shipbuilding project:

2022, 25 January: Contract signing

2022, 13 September: Steel cutting

2022, 30 November: Keel laying

2023, 12 October: Launch

2024, 6 February: Inclining test

IMO 9973717
